18.5 inch pcap pos touchscreen monitor with tempered glass for advertising

  • 10 - 99 Pieces
    $139.00
  • 100 - 499 Pieces
    $135.00
  • 500 - 999 Pieces
    $131.00
  • >=1000 Pieces
    $128.00
Model Number:
THD1852C
Lead Time:
Quantity(Pieces) 1 - 10 11 - 500 501 - 1000 >1000
Est. Time(days) 3 15 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
OEM OR ODM
Screen Size:
18.5 inch
Type:
Capacitive
Interface Type:
D-Sub, DVI, Serial, USB
Resolution:
1366*768
panel:
18.5 inch TFT-LCD
Series:
Metal-cased openframe
Video Input:
VGA and DVI , HD - optional
Contrast:
1000:1
Luminance(cd/m2):
350, 1000cd/m2 - optional
Response Time:
5ms
Support Color:
16.2M colors
Touch System Interface:
USB interface
Input:
100-240 VAC, 50-60 Hz
keywords:
touchscreen monitor, 15 inch touchscreen monitor, openframe monitor
Products Status:
Stock
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard carton
18.5 inch pcap pos touchscreen monitor with tempered glass for adversiting
Port
Shenzhen china
Lead Time :
Quantity(Pieces) 1 - 10 11 - 500 501 - 1000 >1000
Est. Time(days) 3 15 20 To be negotiated

18.5 inch pcap pos touchscreen monitor for adversiting

Product Description



Features of open frame touch screen monitor:

  1. Open frame touch screen monitor sizes : 12.1" / 15" / 17" / 19" / 21.5" / 22", Widescreen or positive screen optional.
  2. Resistive, Capacitive, infrared or SAW touch screen optional.
  3. The high level of brightness together with fast response time and LED backlight technology.
  4. Open frame touch screen monitor for POS / KTV / Gaming / Casino / Industrial use.
  5. Easy to Mount Open Frame,Rugged construction against external impact, metal chassis.
  6. Standard Power supply, Low comsuption and environmental protection.

Specification

General
SeriesMetal-cased openframe
LCD Type18.5 inch TFT-LCD
Video InputVGA and DVI , HD - optional
OSD controlsAllow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset.
Power SupplyType: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface1)VESA 75mm and 100mm
2)Mount bracket, horizontal or vertical
LCD Specification
Active Area(mm)304.8(H)×228.7(V)
Resolution1366*768@75Hz
Dot Pitch(mm)0.297×0.297
Nominal Input Voltage VDD+3.3V(Typ)
Viewing angle (v/h)80°/80°
Contrast1000:1
Luminance(cd/m2)350, 1000cd/m2 - optional
Response Time(Rising/Falling)5s/5s
Support Color16.2M colors
Backlight MTBF(hr)50000
Touchscreen Specification
Typecapacitive
Light Transmission92%
Touch Life Cycle50 millions
Touch Response time2ms
Touch System InterfaceUSB interface
Power consumption+5V@80mA
External AC Power Adapter
OutputDC 12V /4A
Input100-240 VAC, 50-60 Hz
MTBF50000 hr at 25°C
Environment
Operating Temp.0~50°C
Storage Temp.-20~60°C
Operating RH:20%~80%
Storage RH:10%~90%

14 15.6 17.3 18.5.jpg

More Products

Company Information

abeloe (6).jpg

Our Services



Sample Availability & Policy:

Paid samples are available in 3 - 7 days.
Buyer covers the shipping cost, Sample fee can be deducted from the first order
OEM & ODM sample lead time to be discussed.





Product Compliance :



All our Products can be compliant with RoHS, CE, FCC.
We can also do WEEE / REACH Complaint.
Recycle Material Compliant
UL / CSA Complaint can be done upon requirement
PSE / NCC can be done upon requirement



Warranty & Spare parts Conditions :

1. Our Products comes with 3 Year Warranty
2. We offer Premium Quality for Customer to make better profits
3. We maintain High Quality Standard
4. Our Products makes Customer Best Seller Product
5. We provide Best Product for futher sales
6. We sell Original Authentic Product to Customer
7. Our Products are Environment Friendly Products.









 TRADE INFO



                 Trade Terms: FOB, CIF, EXW

                 Payment terms: T/T, Western Union, PayPal, Escrow, MoneyGram.

                 Payment Condition: 30% deposit in advance, 70% balance after delivery

                 Delivery Time:5-7 working days after deposit,3-4 working days for inventory

                 Packing: Neutral Carton, Wooden case for large size

                 Shipping: By sea, by air and by express delivery








Compnay Profile:



        ShenZhen ABELOE Technology Co.,Ltd was established in 2002.,As a High-tech enterprise, we have own professional R&D team,Factory, Marketing and after sales service department. We specialized in LED LCD Monitor, Touch Screen Monitor,CCTV Monitor,Open Frame Monitor, All in One PC ,Advertising Player with 14 years experience,Our products have been widely used in the USA,Europe,Southeast Asia,The Middle East,Africa and other countries and regions. Extra quality is our way to show sincerest respect to our customers.We have passed FCC,CE,RoHS and others.



 - .jpg





Why Choose US ?



Why choose us.jpg
